Fork + PowerUSBhub for $120


Complete set in the box: only 2 board, instructions
Delivery: $30 Savings of $49 compared to the simultaneous purchase of Fork and PowerUSBhub separately!

FORK
  • 8 Digital Outputs can be used as active/passive output, connect a relay or PWM on every channel;
  • 8 Digital Inputs can be used as dry contact with input voltage up to 30V, with frequency measurement and pulse calculation features;
  • 7 Analog Inputs -10..10V with overvoltage protection. Up to 1M Sample rate;
  • 1 Analog Diff Input -1.5..1.5V with overvoltage protection. Up to 1M Sample rate;
  • 2 Analog Outputs 0..10V output with short circuit protection. Sin/triangle/saw/random wave generator features;
  • 4 UARTs or SPI or I2C for connection with external devices like ADC, DAC, external memory, sensors etc.;
  • Ethernet, Wi-Fi to connect with computer, RPi or Smartphone for total galvanic isolation;
  • USB for simple connection with computer, RPi or Smartphone;
  • Supply voltage 5V.
Download 3d model of the case

PowerUSBHub
  • 2 Digital Outputs
  • 2 Digital Inputs
  • Supply voltage 5V
  • Fixed power supplies 3.3В, 500мА, 5В, 300мА
  • Managed power supplies 1.25..32V 5W
  • 4 managed USB hub ports
  • USB and UART management from Fork/PC
  • Spi for connecting the LCD screen

Fork for $79


Complete set in the box: only board, instructions
Delivery: $30

  • 8 Digital Outputs can be used as active/passive output, connect a relay or PWM on every channel;
  • 8 Digital Inputs can be used as dry contact with input voltage up to 30V, with frequency measurement and pulse calculation features;
  • 7 Analog Inputs -10..10V with overvoltage protection. Up to 1M Sample rate;
  • 1 Analog Diff Input -1.5..1.5V with overvoltage protection. Up to 1M Sample rate;
  • 2 Analog Outputs 0..10V output with short circuit protection. Sin/triangle/saw/random wave generator features;
  • 4 UARTs or SPI or I2C for connection with external devices like ADC, DAC, external memory, sensors etc.;
  • Ethernet, Wi-Fi to connect with computer, RPi or Smartphone for total galvanic isolation;
  • USB for simple connection with computer, RPi or Smartphone;
  • Supply voltage 5V.
Download 3d model of the case

PowerUSBhub for $60



Complete set in the box: only board, instructions
Delivery: $30


  • 2 Digital Outputs
  • 2 Digital Inputs
  • Supply voltage 5V
  • Fixed power supplies 3.3В, 500мА, 5В, 300мА
  • Managed power supplies 1.25..32V 5W
  • 4 managed USB hub ports
  • USB and UART management from Fork/PC
  • Spi for connecting the LCD screen
